52KW Swimming Pool Heat Pumps(SHPH-52CV)

group name: Swimming Pool Heat Pumps

Min Order: 5 piece

brand name: Suoher Inverter Heat Pumps Manufacturer

model: SHPH-52CV

Nearest port for product export: Shunde, Nansha

Delivery clauses under the trade mode: FOB

Acceptable payment methods: T/T

update time: Thu, 21 Nov 2024 19:23:50 GMT

contact supplier

Paramtents

Net dimensions 1495*690*1370(mm)
Packing dimensions 1510*720*1490(mm)
Fan motor 250W*2
Water connections 3inch
Compressor Brand Panasonic (Scroll)
Power supply 380V/3PH/50Hz

Packging & Delivery

151cm x72cm x149cm
Min Order5 piece

Briefing

OEM/ODM good price swimming pool heat pumps for heating or cooling.
52KW swimming pool heat pump.

Detailed

1. Electronic expansion valve.

2. R410A refrigerant.

3. Operating ambient temperature range -5~45DegC.

4. Longer titanium coils inside the condenser, higher COP.

5. Low noise fans, durable fan blades.

6. With heat insulation for titanium heat exchanger.

7. Built-in water flow switch.

8. LCD controller with simple operation.

9. OEM/ODM design.

	Model		SHPH-34CV	SHPH-42CV	SHPH-52CV
Specification	Heating capacity*	KW	24	31.8	39.5
	Heating power input*	KW	5.27	7.38	9.18
	Rated current*	A	8.01	11.21	13.95
	COP*		4.55	4.31	4.30
	Heating capacity**	KW	32	42	50.9
	Heating power input**	KW	5.38	7.42	9.22
	Rated current**	A	8.17	11.27	14.01
	COP**		5.95	5.66	5.52
	Max. water temperature	℃	40
	Rated water temperature	℃	27
	Water flow	m³/h	14.50	18.00	22.00
	Net weight	kg	290	540	590
	Gross weight	kg	305	560	610
	Noise	db	62	65	68
	Water connections	inch	3"
	Power supply		380V/3PH/50Hz
	Net dimensions	mm	*14956901075*		*14956901370*
	Packing dimensions	mm	*15107201190*		*15107201490*
Standard components	Compressor	Brand	Panasonic (Scroll)
	Compressor	Quantity	2
	Condenser		PVC+Titanium heat exchanger
	Evaporator		Hydrophilic aluminum foil + internal thread copper pipe
	4-way valve		Yes
	Expansion valve		Sanhua electronic expansion valve
	Fan motor		250W*2
	Cabinet		Galvanized white metal sheet
	Controller		Large LCD screen controller
	High pressure switch		4.2/3.6MPa
	Low pressure switch		0.02/0.15MPa
	Working mode		Heating and Cooling
	Refrigerant		R32
	Circulation pump		No (Optional)
Remarks	1. Unit working temperature : -10℃ to 43℃ 2. Test condition: ambient temp: 15℃/11℃, water inlet: 27℃ *Test condition: ambient temp: 24℃/19℃, water inlet: 27℃ 3. The above is the basic configuration. Water pump is not included in. 4. The above price is based on FOB Guangzhou. 5. The above price is calculated based on the current exchange rate, if the exchange rate fluctuation is over 0.5%,the price will be adjusted accordingly. 6. Payment term: 30% TT in advance, the rest is balanced before the shipment. 7. Delivery time: It depends on the condition of the material inventory, usually 10-30 working days.
